Unidrive M200

Easy to setup
Nidec's most user-friendly drive yet. Designed to make installation simple and quick. All the parameters you need to get started are on the front of the drive. For everything else, there’s the step by step guide that comes in the box.
If you prefer, you’ll find online support at the companion site: www.drive-setup.com
Flexible connectivity
Unidrive M200 gives you freedom to connect with many of the common fieldbuses using the modular ‘SI’ interface port. It can communicate with Ethernet/IP, PROFINET, MODBUS TCP/IP, EtherCAT, PROFIBUS, CANopen and DeviceNet. The AI-485 Adaptor option can also connect to RS485 networks using Modbus RTU.
A reliable workhorse
Nidec's drives keep your machines running, even in the toughest environments. That means working to international standards IEC60068-2-60 to levels defined by IEC721-3-3 2C3.
Technology you can trust
By the time they’re shipped, Nidec will have tested our drives up to forty times. Giving you the confidence to fit Nidec's drives without the worry of premature failure.
Open loop vector or V/Hz Y
Open loop roto flux control (RFC-A) Y
Analogue inputs/outputs 2/1
Digital inputs/outputs/bidirectional I/O 4/0/1
Relay output (configurable) 1
Onboard PLC Y
RS485 comms Modbus RTU (Requires AI-485 adapter) Y
Cloning via SD-Card (Require AI-Backup adapter) Y
NIDEC (CONTROL TECHNIQUES) UNIDRIVEM THREE PHASE, MAX CONTINUOUS 13.5A, MOTOR SHAFT 5.5KW, 7.5HP, 380-480VAC +/-10%
In stock
NIDEC (CONTROL TECHNIQUES) UNIDRIVEM THREE PHASE, MAX CONTINUOUS 3.2A, MOTOR SHAFT 1.1KW, 1.5HP, 380-480VAC +/-10%
In stock
NIDEC (CONTROL TECHNIQUES) UNIDRIVEM THREE PHASE, MAX CONTINUOUS 2.3A, MOTOR SHAFT 0.75KW, 1HP, 380-480VAC +/-10%
In stock
