Lascar - SP 400-EB-W SPLASH PROOF ULTRA LOW PROFILE, LED VOLTMETER, 8 PIN, 3.5 DIGITS, 9.75MM HIGH, WHITE DIGITS

SP400EBW

Images are for illustrative purposes only

Manufacturer: Lascar
LASCAR SPLASH PROOF ULTRA LOW PROFILE, LED VOLTMETER, 8 PIN, 3.5 DIGITS, 9.75MM HIGH, WHITE DIGITS

0 in stock

Alternative Products
This product is currently out of stock. However please see the viable alternative which we have in stock and available for next day delivery. (Order before 4pm)

Compare Products
One Free UK delivery per day for all online orders over £20.00
(Exc Vat)
Limited time only
Why not check out our related items!
  • Information
  • Specification
  • Related
  • Delivery
  • International
  • Alternatives

SP 400-EB-W Splash-Proof LCD Voltmeter White on Black Display

Designed to fit quickly and easily into your panel design the SP 400-EB-W Voltmeter is profile and features an easy-to-read 3.5 digit white on black, 9.75mm in height liquid crystal display complete with a LED backlight for low light conditions. The SP 400-EB-W features a negative rail generator that allows it to measure a signal referenced to its own power supply ground.

Protected against accidental liquid splashes using the included seal the SP 400-EB-W features a 200mV dc full scale reading, user selectable decimal points, low battery warning, auto-zero and auto-polarity. Easy to interface and install, this durable voltmeter plugs directly into a 9-way standard SIL socket and the SP 400 Voltmeter is easily and securely fitted into your panel application using the supplied fixing clip.


The SP 400-EB-W Voltmeter is suitable for a multitude of applications including, low-voltage power supply monitoring, panel mount indication, test boxes, automotive projects and more that demand an economical, low-profile splash-proof voltmeter.

SP 400-EB-W Low Profile LCD Voltmeter Features:

  • Enhanced black LCD with LED backlight
  • Accuracy (overall error) 0.1 % (±1 count)
  • Operating temperature 0 to 50 °C (32 to 122 °F)
  • Sample rate 2.5 samples per second
  • Supply Voltage 4.75 to 7.5 V dc
  • Supply Current 40 / 80 mA
  • Digit height 9.75mm
  • 200mV dc full scale reading
  • Auto-zero and auto-polarity
  • Programmable decimal points
  • Low Battery warning
  • Splash-proof
  • Dimensions 22.4x35.1x16.75mm (including SIL)
  • Panel cut-out 34x21.3mm maximum panel thickness 3mm

Distributed by Kempston Controls

Kempston Controls a UK specialist technical distributor of fuses, sensors and control equipment. If you would like to discuss any of the parts which you see on our online store, please contact our dedicated UK sales centre on +44 (01933) 411411.

More about Kempstons

SP 400-EB-W : SP400EBW Specification

Manufacturer: Lascar

Pricing Unit: Each

Tariff code: 90138030

Generic code: LASCAR

PDF Product Datasheet for SP 400-EB-W (1378 kb)

Declaration of Conformity (402 kb)

All shipping options below are for UK shipping only. Delivery prices below are Exc VAT.

Web Promo Carriage UK standard delivery, usually 1 - 2 days (1 per day, minimum order £20.00) £0.00
Standard 1-2 Days UK standard delivery, usually within 1 - 2 days £7.95
Next Day* Next Day service* £7.95
Express* Express delivery by 10:30am* £18.00
Saturday** Saturday AM service** £35.00
Collect Collection is available from our site - please call if your order is urgent £0.00

Greyed out shipping options indicate services not available, as the certain criteria has not been met. (i.e. it’s after the cut off time or items in your basket are not in stock for Next Day, Express or Saturday delivery)

* Delivery services are subject to exception areas, click exceptions to view the affected areas or use the ‘shipping estimator’ tool to view delivery options.

International Delivery

We can provide international shipping to 240+ countries worldwide. Please select your country so we can provide you with delivery date and cost estimates.

International Priority – Terms DAP to Delivery Address

For our overseas customers, we offer a very competitive and fast delivery service; however, if you prefer to collect using your own courier, then we can also arrange that at no extra cost.

Price: £28.45
Our Price
£26.26
£31.51 (IncVAT)
Limited availability at this price
In Stock
LASCAR LCD VOLTMETER, 3.5 DIGIT 12.5MM HIGH, LOW PROFILE, FULL SCALE, AUTO ZERO AND POLARITY
Price: £24.95
Our Price
£23.03
£27.64 (IncVAT)
Limited availability at this price
In Stock
LASCAR COMPACT 3.5 DIGIT LCD VOLTMETER, 5.5MM HIGH, LED BACKLIT, FULL SCALE, AUTO ZERO
Price: £29.95
Our Price
£27.65
£33.18 (IncVAT)
Limited availability at this price
Out of Stock
LASCAR DIGITAL VOLTMETER DC, LCD DISPLAY 38X18MM, 3.5DIGITS

Our technical team can help find an alternative! Fill in the below to get started.


What our Customers are saying


Product Compare

Some of these products may not be direct replacements! Please read the products documentation or refer to the Technical Helpdesk for essential product information.

Current

Lascar - SP 400-EB-W - Digital Panel Meters

SP 400-EB-W

£22.11
LASCAR SPLASH PROOF ULTRA LOW PROFILE, LED VOLTMETER, 8 PIN, 3.5 DIGITS, 9.75MM HIGH, WHITE DIGITS

Alternative

Lascar - DPM 125

DPM 125

£26.26

LASCAR LCD VOLTMETER, 3.5 DIGIT 12.5MM HIGH, LOW PROFILE, FULL SCALE, AUTO ZERO AND POLARITY

6 in stock



Lascar - DPM 1AS-BL

DPM 1AS-BL

£23.03

LASCAR COMPACT 3.5 DIGIT LCD VOLTMETER, 5.5MM HIGH, LED BACKLIT, FULL SCALE, AUTO ZERO

6 in stock



Lascar - DPM 340
